Diamax

Cyclone Incremental Bits

Cyclone Incremental Bits

Availability

Ships to you

In-store

SKU

FBSTIP

$63.99 USD
$63.99 USD
Sale Sold out
View full details

  • Description

  • Specs & Support

Description

  • For use on sink cut-out machines
  • Tapered bits have M12 thread (1/2 gas male thread)
  • New Super Cyclone screw on tip is taller and lasts longer for more cutouts with less glazing issues

Tools Can Be Used On

CNC machine

Uses

Wet only

Materials

Engineered stone, granite, marble

Specs & Support

Item # Size Fitting Bond Max RPM Suggested Feed Rate
FBSTIP 20 mm Cyclone M12 Soft 4,000 30″ – 40″ / PM
FBSTIP-S 22 mm Super Cyclone M12 Hard 4,000 30″ – 40″ / PM
FBSTIP-T Tapered 20 mm Super Cyclone M12 Hard 4,000 30″ – 40″ / PM
FBSTIP-RT Reverse thread, 20 mm Super Cyclone M12 Hard 5,500 30″ – 40″ / PM

  • For use on sink cut-out machines
  • Tapered bits have M12 thread (1/2 gas male thread)
  • New Super Cyclone screw on tip is taller and lasts longer for more cutouts with less glazing issues

Tools Can Be Used On

CNC machine

Uses

Wet only

Materials

Engineered stone, granite, marble

Item #FBSTIP
Size20 mm Cyclone
FittingM12
BondSoft
Max RPM4,000
Suggested Feed Rate30″ – 40″ / PM
Item #FBSTIP-S
Size22 mm Super Cyclone
FittingM12
BondHard
Max RPM4,000
Suggested Feed Rate30″ – 40″ / PM
Item #FBSTIP-T
SizeTapered 20 mm Super Cyclone
FittingM12
BondHard
Max RPM4,000
Suggested Feed Rate30″ – 40″ / PM
Item #FBSTIP-RT
SizeReverse thread, 20 mm Super Cyclone
FittingM12
BondHard
Max RPM5,500
Suggested Feed Rate30″ – 40″ / PM
